25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation
  • 25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation
  • 25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation
  • 25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation
25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation

25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation

Place of Origin China
Brand Name Eternalwin
Certification CE
Model Number EW
Product Details
Color:
Customized
Warranty:
1 Year
Usage:
Lifting
Weight:
6,800 Kg
Power Source:
Electric / Diesel Engine
Customized Boom Length:
Available
Load Capacity:
25ton-25ton
Loading Capacity:
5T 8T 10T 12T 16T 20T 25T
Highlight:

25T Folding Boom Crane

,

Dual Hydraulic Winch System

,

Man Basket Aerial Work

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 6,800-32,000 / Unit
Packaging Details
Steel transport frame with waterproof export film and fumigated wooden cases for accessories
Delivery Time
20-30 days
Payment Terms
L/C,T/T,Western Union
Supply Ability
200unit/month
Product Description
25T Heavy Duty Folding Boom Truck Crane Dual Winch Man Basket 360° Rotation
Our 25 ton heavy duty folding boom crane series combines robust steel construction with high pressure hydraulic systems to deliver exceptional lifting and aerial work performance for contractors who need one machine for both jobs.
Five folding boom sections reach 22.8 m, two independent hydraulic winches allow a main hook and an auxiliary hook to work without re-reeving, and the certified man basket turns the crane into an aerial platform.
Key Features & Benefits
  • Five-section folding boom with 22.8 m lifting height and 19.5 m radius
  • Dual hydraulic winches with independent brakes for main and auxiliary hooks
  • Certified 300 kg man basket with hydraulic leveling and harness points
  • H-type outriggers with 6,200 mm span and hydraulic locking pins
  • 360-degree continuous rotation for optimal positioning
  • Load moment indicator with color display and data logging
  • CE certified for quality assurance and customs clearance
  • Customizable boom configurations to meet specific requirements
Technical Specifications
ModelEW25F
Maximum Lifting Capacity25,000 kg at 2.5 m
Maximum Lifting Moment45 t.m
Boom Type5-section folding boom
Maximum Working Radius19.5 m
Maximum Lifting Height22.8 m
Rotation Angle360° continuous
Outrigger Span6,200 mm hydraulic H-type
Winch Capacity25,000 kg main and 5,000 kg auxiliary
Man Basket Capacity300 kg certified
Crane Weight6,800 kg
Recommended Chassis25 t and above, 6x4 or 8x4
Boom length, outrigger span and mounting brackets can be customized to your chassis and local road regulations.
Applications
Heavy machinery installation, Wind and power maintenance, Bridge construction support, Steel plant maintenance, Signage and lighting installation, Port cargo handling.
Packaging & Delivery
The crane is shipped on a steel transport frame with the boom folded and locked, outrigger beams retracted, man basket packed separately in a wooden case, and all hydraulic ports sealed for ocean freight.
Client Visits & Support
We welcome client visits to our manufacturing facilities to inspect product quality and discuss custom requirements. Our technical team provides comprehensive support throughout the entire process, including chassis matching, installation drawings and after-sales spare parts supply.
